H4101070310A0 Engine Front Right Bracket High-Strength Mount For Foton Auman GTL EST Cummins ISG

Product Overview​

The H4101070310A0 engine front right bracket is a critical load-bearing and shock-absorbing component exclusively designed for Foton Auman heavy-duty trucks, including GTL and EST series equipped with Cummins ISG engines. As the key connection between the vehicle chassis and engine, it secures the powertrain in place while absorbing vibrational energy and torque reactions during operation . Adopting a reinforced T-type structure with dual triangular 加强筋 (reinforcement ribs) and a central transverse rib, it solves common faults such as engine displacement, abnormal frame vibration and mounting point cracking caused by aging or damaged brackets . Widely used in long-distance logistics tractors, heavy cargo trucks and engineering transport vehicles, it ensures stable power transmission and driving safety under heavy-load and harsh working conditions.​

Core Product Advantages​

1. Reinforced T-Type Structural Design: Engine 连接板 (engine connecting plate) and 橡胶支撑连接板 (rubber support plate) form a T-type structure, enhanced by dual triangular side ribs and a central transverse rib to form an "I-beam" reinforcement system , reducing maximum stress by 40% and preventing deformation under extreme loads.​

2. High-Strength Material Combination: Q235 high-carbon steel bracket body (tensile strength ≥510MPa) combined with vulcanized rubber damping pad , ensuring structural rigidity while isolating 85% of engine vibration transmitted to the chassis .​

3. Precision Manufacturing & Perfect Fit: CNC hydraulic forging and plasma cutting ensure mounting hole position accuracy within ±0.1mm , perfectly matching Foton Auman's original chassis layout and Cummins ISG engine mounting points.​

4. Superior Vibration Damping & Noise Reduction: High-elasticity rubber pad with Chemlok® hot vulcanization bonding , effectively absorbing engine torque fluctuations and road impact, reducing cab noise by 15-20dB during operation.​

5. Anti-Corrosion & Long Durability: Surface shot blasting + electrostatic powder coating treatment , resisting mud, rainwater and road salt erosion; passes 100,000km road test and 5,000-cycle impact fatigue test .​

6. Plug-and-Play Installation: Consistent with Foton Auman's standard mounting dimensions and bolt specifications , no drilling or bracket modification required, completing replacement in 45 minutes with basic tools.​

7. Wide Temperature Adaptability: Rubber damping pad maintains stable performance in -40℃~+80℃ , adapting to cold plateaus, high-temperature engine compartments and harsh working environments.​

Basic Product Parameters​

• Part Number: H4101070310A0​

• Product Name: Engine Front Right Bracket / Mount Support​

• Applicable Vehicle: Foton Auman GTL, EST series heavy-duty commercial trucks​

• Applicable Engine: Cummins ISG series diesel engines​

• Core Material: Q235 high-carbon steel + vulcanized rubber damping pad​

• Structural Feature: T-type frame + dual triangular reinforcement ribs + central transverse rib​

• Operating Temperature: -40℃ ~ +80℃​

• Core Function: Engine fixation, vibration isolation, chassis protection​

• Installation Position: Vehicle chassis front right side (engine connection point)​

• Package: Neutral export carton, shockproof foam inner packaging with anti-scratch film​

Application Scenarios​

Ideal replacement chassis part for Foton Auman long-haul tractors, heavy cargo trucks, engineering dump trucks and logistics transport vehicles equipped with Cummins ISG engines. Suitable for long-distance highway transportation, mountain full-load haulage, construction site operations and harsh road conditions. It effectively prevents engine displacement, reduces chassis fatigue damage and improves driver comfort during long journeys.​

Purchase Reminder​

Please confirm your Foton Auman model (GTL/EST) and engine type (Cummins ISG) before ordering to ensure perfect matching. We support bulk wholesale for global auto parts distributors and fleet maintenance centers, with sufficient stock and competitive bulk pricing. The product comes with a 12-month warranty; our technical team provides remote installation guidance and compatibility confirmation upon request. For bulk orders, custom packaging services are available.​
